About brandLithium batteries sold for off-grid, marine, RV and home storage uses.
SKU detail
locator: LiTime US product data (products.json, page 1), listing "LiTime 16V 100Ah Lithium Battery for LiveScope & Fish Finder Systems with Bluetooth and Self-Heating" (handle litime-16v-100ah-fish-finder-lithium-battery), option "1 Pack", "sku":"L16V100-100-MELE-HEAT-BT-5-A90"
conditions: LiTime's own US product data, captured October 27, 2026, prints SKU "L16V100-100-MELE-HEAT-BT-5-A90" for option "1 Pack" (variant 46455503945948) of listing "LiTime 16V 100Ah Lithium Battery for LiveScope & Fish Finder Systems with Bluetooth and Self-Heating".
locator: Variant data of the archived listing, "Like New" variant SKU
conditions: Like New (refurbished) listing on LiTime's US store, archived February 7, 2026; the page prints SKU "L16V100-100-MELE-HEAT-BT-5-A90-Like New" for its Like New variant.
LiTime publishes gtin12 702571567554 against SKU L16V100-100-MELE-HEAT-BT-5-A90 in the structured product data on its own product page. Package, bundle and regional variants carry separate codes; no code is carried to another variant.
Printed as "Bluetooth √" in the specification table on LiTime's own product page for L16V100-100-MELE-HEAT-BT-5-A90, captured on September 22, 2026. LiTime marks the feature present with a tick in its own table; no Bluetooth version, profile or range is published.
Printed as "LiFePO4" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Cell Type. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Printed as "M8*1.25mm Positive Terminal; M8*1.25mm Negative Terminal" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 2, Product Overview. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Printed as "Weight Approx. 26.48lbs" in the specification table on LiTime's own product page for L16V100-100-MELE-HEAT-BT-5-A90, captured on September 22, 2026. Converted at 1 lb = 0.45359237 kg and rounded to three decimals where LiTime publishes the figure in pounds only. LiTime calls it approximate and publishes no tolerance.
Printed as ">=4000 times" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Cycle Life. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Printed as "100Ah" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Rated Capacity. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Printed as "Self-Heating √" in the specification table on LiTime's own product page for L16V100-100-MELE-HEAT-BT-5-A90, captured on September 22, 2026. LiTime marks the feature present with a tick in its own table.
Printed as "500A@1 second" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Surge Discharge Current. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Where: page 3, Battery Parameters, Surge Discharge Current
Printed as "100A" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Battery Management System (BMS) Board. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Where: page 3, Battery Parameters, Battery Management System (BMS) Board
Printed as "ABS" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 4, Housing Material. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
W 169.9 × H 211.1 × L 308.1 mm / W 6.69 × H 8.31 × L 12.13 in
Printed as "Size 12.13*6.69*8.31 inch (BCI Group 27)" in the specification table on LiTime's own product page for L16V100-100-MELE-HEAT-BT-5-A90, captured on September 22, 2026. Length, width and height follow LiTime's own L x W x H order; the row is converted from inches at 1 in = 25.4 mm.
Location: LiTime 16V 100Ah Smart Self-Heating Battery user manual (September 20, 2026 capture), page 1, cover title "Marine Electronics x Group 27" (image-only PDF, read by OCR)
Enclosure rating
IP65
Printed as "IP65" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 4, Protection Class. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Printed as "Max. Expansion (Parallel & Series) 4P1S" in the specification table on LiTime's own product page for L16V100-100-MELE-HEAT-BT-5-A90, captured on September 22, 2026. LiTime prints the series and parallel limits together in one row.
Printed as "100A" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Max. Continuous Charge Current. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Where: page 3, Battery Parameters, Max. Continuous Charge Current
The LiTime 16V 100Ah self-heating battery product manual (image-only document, read from the rendered pages) prints "Surge Discharge Current 500A@1 second" on PDF page 3; captured on September 26, 2026.
Printed as "16V" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Nominal Voltage. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Where: page 3, Battery Parameters, Nominal Voltage
Printed as "Support connecting up to 4 identical batteries in parallel" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 6, Limitation for Series/Parallel Connection. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Where: page 6, Limitation for Series/Parallel Connection
Printed as "1600Wh" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Energy. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
The LiTime 16V 100Ah self-heating battery product manual (image-only document, read from the rendered pages) prints "Recommended Terminal Torque 106.2 to 123.9 inch·lbs / 12 to 14 N·m" on PDF page 4; captured on September 26, 2026.
Printed as "100A" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Max. Continuous Charge Current. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Where: page 3, Battery Parameters, Max. Continuous Charge Current
Printed as "100A" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Max. Continuous Discharge Current. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Where: page 3, Battery Parameters, Max. Continuous Discharge Current
Printed as "Charge: -20°C to 50°C / -4°F to 122°F" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 4, Temperature Range, Charge. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Printed as "1600W" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 4, Max. Continuous Output Power. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Printed as "Heating Temperature -20°C to 5°C / -4°F to 41°F" in the specification table on LiTime's own product page for L16V100-100-MELE-HEAT-BT-5-A90, captured on September 22, 2026. The temperature the heater starts at; LiTime publishes no heater power, no stop temperature and no heating current draw. — Corrected on 22 September 2026: the catalogue had published -20 °C, which is the bottom of the printed "-20°C to 5°C" heating range. A heater switches on as the temperature falls past the upper end, which is how this catalogue reads the identical printed string for Redodo and Pytes. The figure above is read from the same printed text this record already quotes; no new source and no new claim.
Printed as "18.0±0.25V" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Charge Voltage. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Printed as "20A (0.2C)" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Recommended Charge Current. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Where: page 3, Battery Parameters, Recommended Charge Current
Printed as "Storage: -10°C to 50°C / 14°F to 122°F" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 4, Temperature Range, Storage. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Printed as "100A" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Max. Continuous Discharge Current. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Where: page 3, Battery Parameters, Max. Continuous Discharge Current
Printed as "Discharge: -20°C to 60°C / -4°F to 140°F" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 4, Temperature Range, Discharge. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
LiTime's "Certifications" row on its own product page for L16V100-100-MELE-HEAT-BT-5-A90, captured on September 22, 2026, lists FCC, CE, RoHS, UN38.3 and FCC ID. The exact string the row prints is the value recorded here and is re-checked against the capture on every run. Marks LiTime lists on its own page; no certificate number, issuer record or test report was read for any of them.
Printed as "10A" in the LiTime 16V 100Ah Smart Self-Heating Battery user manual, page 3, Battery Parameters, Required Minimum Charge Current for Heating Function. Revised on 30 September 2026: Re-cited to LiTime's own document: the earlier source was a capture of a litime.com page, whose robots.txt disallows AI agents (Project Manager, September 30, 2026); the value is unchanged.
Where: page 3, Battery Parameters, Required Minimum Charge Current for Heating Function
The LiTime 16V 100Ah self-heating battery product manual (image-only document, read from the rendered pages) prints "Low Temperature Charging Protection(LTCP) Function Yes" on PDF page 4; captured on September 26, 2026.
The LiTime 16V 100Ah self-heating battery product manual (image-only document, read from the rendered pages) prints "the BMS stops battery charging when the battery temperature falls below 0°C/32°F" on PDF page 4; captured on September 26, 2026. Charging resumes above 5°C/41°F.
The Evidence score uses the priorities you choose. It counts published documents, such as certificates and warranty terms, and it compares a documented figure with the best documented figure of the same kind. It does not count owner reviews, and it is not a verdict on product quality or on how many people have reviewed it. A low score can mean little is documented, or that a documented figure is below the best of its kind. Undisclosed data scores 0.
Missing details. This number counts only the evidence recorded so far. The source review for this product is not finished, or the maker has not disclosed enough, so the number can only go up.
Missing for this product: Certificates evidence needed; Warranty energy disclosure evidence needed; Cell model disclosure evidence needed.
12 V · Case battery · Rated capacity
The warranty term and the lifetime energy are each scored against the best documented value for a home storage battery: a value earns its share of that best, times the weight. A documented value always earns points; an undisclosed one earns 0.
LiTime prints "Warranty 5 Years" on its own product page for L16V100-100-MELE-HEAT-BT-5-A90, captured on September 22, 2026. LiTime’s Warranty Policy page carries the matching row "1 6 V series:≥ 3 0Ah 5 years". The term runs from installation or receipt by the original consumer purchaser, a purchase receipt is required to establish the start date, and the cover is limited to that purchaser.
Research pending, 0 points: Certificates, Warranty energy disclosure, Cell model disclosure.
Computed from public specifications and evidence records. Warranty duration is not service quality; certificate evidence points are not a safety rating. Compatibility and installation limits still apply.
What this shows: what each record says and how far it reaches. It does not mean the product is approved.
StandardEvidenceStatusSource
UN 38.3manufacturer claimpresent at observation[4]
Scope
pack
Covered models
L16V100-100-MELE-HEAT-BT-5-A90
Limitations
LiTime prints "Certifications FCC,CE,RoHS,UN38.3,FCC ID" in the specification table of its own product page for L16V100-100-MELE-HEAT-BT-5-A90, captured on September 22, 2026. UN 38.3 is the United Nations transport test series for lithium batteries, not a safety listing: it says the pack may be shipped, not that it is listed for installation. No test report, test summary, laboratory identity or issue date was read, and LiTime publishes none, so nothing here is verified beyond the manufacturer's own claim on its retail page.
Repair at LiTime expense; where the product cannot be repaired, a free replacement of the same or an equivalent model, carrying the longer of the original term or a further 90-day repair warranty
Printed as "LiTime will repair, at LiTime 's expense, any LiTime product that fails to operate during the applicable warranty period due to a defect in workmanship or material." (LiTime's own spacing) on LiTime's Warranty Policy page captured on September 22, 2026. Replacements may be refurbished but must be functionally equivalent. No labour allowance and no shipping term is printed.
Where: Warranty Policy page, section "6 . Repair or replacement"
Original consumer purchaser only; not transferable to a subsequent owner
Printed as "is limited to the original consumer purchaser and is not transferable to any subsequent owner" on LiTime's Warranty Policy page captured on September 22, 2026. A second-hand buyer therefore has no cover at all under the published terms.
Where: Warranty Policy page, section "7. Limited to Original Consumer Buyer"
Excludes misuse, abuse, modification, accident damage and any use outside normal consumer use as authorised in LiTime product literature; excludes attempted repair by anyone other than an authorised facility; excludes any product bought through an online auction house
Summarised from the three numbered exclusions printed on LiTime's Warranty Policy page captured on September 22, 2026. The page prints no wear-out, capacity-retention or cycle-count exclusion and no energy-throughput limit, so a capacity complaint is not addressed by the published text.
Date of installation or receipt by the original consumer purchaser, evidenced by the first purchase receipt
Printed as "the warranty period is measured starting on the date of installation or receipt by the original consumer purchaser" on LiTime's Warranty Policy page captured on September 22, 2026; the page adds that the first consumer sales receipt or other reasonable documentary proof is required to establish that date.
LiTime prints "Warranty 5 Years" on its own product page for L16V100-100-MELE-HEAT-BT-5-A90, captured on September 22, 2026. LiTime’s Warranty Policy page carries the matching row "1 6 V series:≥ 3 0Ah 5 years". The term runs from installation or receipt by the original consumer purchaser, a purchase receipt is required to establish the start date, and the cover is limited to that purchaser.
Original manufacturer-hosted PDF preserved byte for byte, downloaded from the link published on LiTime's own product page for SKU L16V100-100-MELE-HEAT-BT-5-A90. The revision is whatever was served at this URL on the access date; no later revision was checked, no issuer or laboratory record was read against anything the document states, and no coverage is claimed beyond the SKU whose page linked it.
Archived copy of a document published by LiTime. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Reached from the footer link "Warranty Policy"; not in the product sitemap.
Location: Sections "1. Limited Warranty", "2. Warranty Period" (New Product and Like New Product tables), "6 . Repair or replacement", "7. Limited to Original Consumer Buyer", "8. Exclusions"
Retrieved Sep 21, 2026
LiTime's published Warranty Policy page, linked from the footer of every page on litime.com and captured byte for byte on September 22, 2026. It establishes the terms LiTime published on the access date: a limited warranty against defects in workmanship and material under normal consumer use; a Warranty Period table that gives new batteries five years by voltage class and minimum capacity (12V from 20Ah, 16V from 30Ah, 24V from 25Ah, 36V from 50Ah, 48V at any capacity, 51.2V from 30Ah), charge controllers three years, AC-DC and DC-DC chargers two years, 12V 1000W/2000W/3000W inverters two years, and monitors, busbars, switches, circuit breakers and battery boxes one year; a shorter table for Like New product; repair at LiTime's expense or a free equivalent replacement with a further 90-day repair warranty; a term that starts at installation or receipt by the original consumer purchaser and needs a receipt; and the exclusions. It states plainly that the warranty is limited to the original consumer purchaser and is not transferable. It is a web page, not a signed warranty contract: it carries no revision date or version, names no per-SKU term, and establishes no claim outcome. Where a product page prints a term for a model the policy table's capacity floor would exclude, the page figure is recorded and the conflict is written into that product's identity note.
Location: Variant data: SKU of the "Like New" variant
Retrieved Sep 30, 2026
LiTime's own US store listing of a Like New (refurbished) unit, as archived by the Internet Archive at snapshot 20260207072331 (February 7, 2026). It shows what the page printed on that date, not today. The live store disallows AI agents in its robots.txt, so it was not read.
Captured during the September 21-22 brand-by-brand catalogue sweep, one request per second, robots.txt honoured (LiTime disallows /search, /policies/, /collections/*sort_by* and /a/downloads/-/*).
Location: Title "LiTime 16V 100Ah Fish Finder Lithium Battery for Livescope"; Specs tab (BATTERY, BMS, CHARGE, TEMPERATURE, SELF-HEATING, OTHERS); User Manual tab; variant selector
Retrieved Sep 21, 2026
Manufacturer-operated product page for L16V100-100-MELE-HEAT-BT-5-A90 (LiTime 16V 100Ah Lithium Battery for LiveScope & Fish Finder Systems with Bluetooth and Self-Heating), captured byte for byte on September 22, 2026 during a crawl of every one of the 244 products LiTime lists at litime.com/collections/all/products.json. It establishes what LiTime published on the access date and nothing more: the product title, the variants and their SKUs and prices, the marketing description, the specification table under the Specs tab (BATTERY, BMS, CHARGE, TEMPERATURE, SELF-HEATING, OTHERS sections), the documents offered under the User Manual tab (LiTime_16V_100Ah_Smart_Self-Heating_Battery_-_User_Manual_20903acb-a590-4a83-96e8-58a47d4c2b2e.pdf) and the photographs the page publishes. Every figure this pass reads from it is a row of that table, quoted here with the exact string the row prints. It is a retail page, not a datasheet: LiTime publishes no test conditions, no cell maker, no certificate numbers and no revision date for it, and where it disagrees with a value the catalog already records the disagreement is written into the product identity note rather than resolved. Prices and stock shown on it are the September 22 state of a promotional page and are not recorded as facts.
Manufacturer-operated store product page captured byte for byte and matched to this catalog row on an exact manufacturer SKU match against the published variant SKU L16V100-100-MELE-HEAT-BT-5-A90. It establishes what LiTime published on that page on the access date: the specification rows printed there, the SKU and barcode in the page's own structured data, the documents linked from it and the photo it shows. Marketing copy, certification wording and stock state on the page remain manufacturer claims that no issuer or laboratory record was read against, and nothing here is carried to another variant.
Archived copy of a document published by LiTime. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Order: products a manufacturer names first, then by Evidence score at default weights.
Matched on printed specifications only: each manufacturer's datasheet, as recorded on the product pages. A match means one product's printed figure falls inside the other's printed limit. It does not mean the two have been shown to work together. A figure a manufacturer does not print shows as Not documented and is never assumed. This is not a test or an approval. A qualified installer and the local code decide what can be connected.
Parts and accessories
No sourced accessories or replacement parts listed yet.
Model history
Model identity
Model
L16V100-100-MELE-HEAT-BT-5-A90
Manufacturer SKU L16V100-100-MELE-HEAT-BT-5-A90
No historical observations recorded yet.
Other recorded fields
Field
Value
Conditions
Source
Evidence breakdown
method version: 0.21-personal
documented pct: 40
basis: nominal
missing:
Certificates evidence needed
Warranty energy disclosure evidence needed
Cell model disclosure evidence needed
criteria:
key: certificateEvidence
label: Certificates
value: 0
unit: evidence points
shown: UN 38.3
shown detail: Research pending
state: pending
points: 0
ceiling: 45
weight: 45
share: 0
covered: no
missing: yes
folded: yes
reason: Unknown
reason text: Unknown
note: No qualifying applicable evidence recorded. This is not proof that certification is absent. Applies: UL 1973; CEC not applicable to 12 V / 24 V / 36 V DC modules; UL 9540 not applicable to 12 V / 24 V / 36 V DC modules.
