Printed as "via Bluetooth to devices such as mobile phones and tablets" in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 14, 6.4 Battery Management System Bluetooth Communication). One value printed for all four models of the manual, including the AES-B-GC12-24V.
Where: PDF page 14, 6.4 Battery Management System Bluetooth Communication
At least 50 mm (2 in) above the top cover; no zero-clearance compartments
Printed as "Do not install in zero-clearance compartments."; "Maintain at least 50 mm (2 inches) above the top cover for open airflow." in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 17, 7.2 Location, item 4). One value printed for all four models of the manual, including the AES-B-GC12-24V.
Standard battery tray with B1/B3 hold-down ledges, or over-the-top hold-downs
Printed as "designed with standard B1/B3 hold-down ledges for use with standard battery trays"; "The battery may also be strapped in place with over-the-top hold-downs." in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 17, 7.2 Location, item 6). One value printed for all four models of the manual, including the AES-B-GC12-24V.
Printed as "Terminal M8 Terminal Terminal Torque"; "Positive M8 Button Terminal (16 mm depth)" in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (pages 8, 13, 3.2 Mechanical Specifications; 6 Features, Figure 2). One value printed for all four models of the manual, including the AES-B-GC12-24V.
Charged Reviews classified this product from the documents it is based on. It is our own grouping, not a manufacturer claim.
Printed as "Industry Reference G24 G24 GC12 GC12", with GC12 for this model. Classified as Case battery from the maker's own words for this model: GC12 is a BCI group size the format list accepts since #1869 (PM decision, October 13, 2026: an accepted BCI group is a case word).
Location: LITHIUM BLUE leaflet (Discover, lithium-blue-v2-leaflet-2026-01), page 2, specification table, Industry Reference row (columns AES-B-G24-12V-H, AES-B-G24-24V, AES-B-GC12-12V-H, AES-B-GC12-24V)
Enclosure rating
IP67
Printed as "IP Rating IP67 Case Material" in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 8, 3.2 Mechanical Specifications, IP Rating row). One value printed for all four models of the manual, including the AES-B-GC12-24V.
Where: PDF page 8, 3.2 Mechanical Specifications, IP Rating row
Printed as "Nominal Voltage 12.8 V 25.6 V 12.8 V 25.6 V" in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 7, 3.1 Electrical Specifications, Table 3-1, Nominal Voltage row). The AES-B-GC12-24V value is the fourth of the four model columns (AES-B-G24-12V-H, AES-B-G24-24V, AES-B-GC12-12V-H, AES-B-GC12-24V). Specifications are published at 25°C.
Where: PDF page 7, 3.1 Electrical Specifications, Table 3-1, Nominal Voltage row
Printed as "Do not install the battery in series." in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 4, 1.3 General Warnings; 7 Installation). One value printed for all four models of the manual, including the AES-B-GC12-24V.
Where: PDF page 4, 1.3 General Warnings; 7 Installation
Fuse 200 A; There is an inline fuse in the positive terminal
Printed as "Fuse 200 A 80 A 250 A 200 A"; "There is an inline fuse in the positive terminal" in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (pages 7, 31, Table 3-1 Fuse row; 11 Replacing the Fuse). The AES-B-GC12-24V value is the fourth of the four model columns (AES-B-G24-12V-H, AES-B-G24-24V, AES-B-GC12-12V-H, AES-B-GC12-24V). The BMS also protects against overvoltage, undervoltage, overcurrent and temperature.
Where: PDF pages 7, 31, Table 3-1 Fuse row; 11 Replacing the Fuse
Printed as "Terminal Torque 8 to 10 Nm (5.9 to 7.4 ft-lb). DO NOT EXCEED 10 Nm" in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 8, 3.2 Mechanical Specifications, Terminal Torque row). One value printed for all four models of the manual, including the AES-B-GC12-24V.
Where: PDF page 8, 3.2 Mechanical Specifications, Terminal Torque row
Printed as "Install the battery in any direction other than upside down." in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 17, 7.2 Location, item 5). One value printed for all four models of the manual, including the AES-B-GC12-24V.
Printed as "Recommended Charge Current 50 A 22.5 A 100 A 50 A" in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 7, 3.1 Electrical Specifications, Table 3-1, Recommended Charge Current row). The AES-B-GC12-24V value is the fourth of the four model columns (AES-B-G24-12V-H, AES-B-G24-24V, AES-B-GC12-12V-H, AES-B-GC12-24V).
Where: PDF page 7, 3.1 Electrical Specifications, Table 3-1, Recommended Charge Current row
Additional DC overcurrent protection and a DC disconnect, located close to the battery in the positive cable
Printed as "additional DC overcurrent protection and a DC disconnect are recommended"; "should be located close to the battery and installed in the positive cable" in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 18, 7.4 DC Protection). One value printed for all four models of the manual, including the AES-B-GC12-24V.
Printed as "The ambient temperature should be between 0°C and 40°C (32°F and 104°F)." in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 16, 7.2 Location, item 2). One value printed for all four models of the manual, including the AES-B-GC12-24V. Ambient installation temperature; 15°C to 25°C is given as ideal.
Printed as "Low Voltage Disconnect (1) 10 V 20 V 10 V 20 V"; "Low Voltage Disconnect is based on 2.5 VPC under load." in the Lithium BLUE Installation and Operation Manual, 805-0083 Rev C (page 7, 3.1 Electrical Specifications, Table 3-1, Low Voltage Disconnect row). The AES-B-GC12-24V value is the fourth of the four model columns (AES-B-G24-12V-H, AES-B-G24-24V, AES-B-GC12-12V-H, AES-B-GC12-24V). The table separately recommends a Low Voltage Disconnect of 12 V / 24 V for the power conversion equipment.
Where: PDF page 7, 3.1 Electrical Specifications, Table 3-1, Low Voltage Disconnect row
15.24 L* (Calculated enclosure volume: W × H × D in mm ÷ 1,000,000)W: 312 × H: 276 × D: 177 mm / W: 12.2 × H: 10.9 × D: 7 in20 kg / 44 lb0.17 kWh/L* (Rated or usable capacity shown on this card ÷ enclosure volume)
Evidence score
5/100Missing details20% documented
The Evidence score uses the priorities you choose. It counts published documents, such as certificates and warranty terms, and it compares a documented figure with the best documented figure of the same kind. It does not count owner reviews, and it is not a verdict on product quality or on how many people have reviewed it. A low score can mean little is documented, or that a documented figure is below the best of its kind. Undisclosed data scores 0.
Missing details. This number counts only the evidence recorded so far. The source review for this product is not finished, or the maker has not disclosed enough, so the number can only go up.
Missing for this product: Certificates evidence needed; Warranty energy disclosure evidence needed; Lifetime / capacity evidence needed; Cell model disclosure evidence needed.
24 V · Case battery · Rated capacity
The warranty term and the lifetime energy are each scored against the best documented value for a home storage battery: a value earns its share of that best, times the weight. A documented value always earns points; an undisclosed one earns 0.
Discover's Lithium BLUE Warranty Policy (885-0063 REV A, guarantor Discover Battery Corp.; PDF on discoverbattery.com captured on October 23, 2026) lists AES-B-GC12-24V (24V / 2560 Wh) in its warranty table with a Workmanship Warranty Period of "5 years", printed as one cell spanning all four listed models (AES-B-G24-12V-H, AES-B-G24-24V, AES-B-GC12-12V-H and AES-B-GC12-24V), an Annual Energy Throughput Limit of 1590 kWh and a Total Energy Throughput Limit of 4.7 MWh (the two throughput cells are printed across AES-B-GC12-12V-H and AES-B-GC12-24V). It prints that Discover "warrants to the original product purchaser (User), that your Lithium BLUE Premium Lithium Battery (Battery) is free from manufacturing defects that would prevent the battery from delivering unlimited cycles while maintaining at least 60% of the original Rated Wh for the earlier of the listed ‘Workmanship Warranty Period’ or ‘Total Energy Throughput Limit’." The warranty is headed "NON-TRANSFERABLE LIMITED PERFORMANCE WARRANTY"; the period is "the total period in years from the initial installation date"; registration is printed as optional ("Optional Registration at https://www.discoverlithium.com."). The warranty is void if the battery "surpasses the Annual Energy Throughput Limit in any 12-month period" or "is used in a Stationary Renewable Energy Storage application with a nominal voltage greater than 24VDC", among the other listed exclusions; a credit or refund after a claim covers the unused years of the period. "This Limited Warranty is effective for sales of Batteries occurring after June 24th, 2025."
Research pending, 0 points: Certificates, Warranty energy disclosure, Cell model disclosure.
Computed from public specifications and evidence records. Warranty duration is not service quality; certificate evidence points are not a safety rating. Compatibility and installation limits still apply.
Discover's own product page for AES-B-GC12-24V names "UN 38.3" in its certification block. This is a manufacturer statement recorded against that exact model page: no issuer listing, certificate number, edition, scope or validity was checked, and the lead-acid pages word it as designed in accordance with the standard rather than as a certification.
Discover's Lithium BLUE Warranty Policy (885-0063 REV A, guarantor Discover Battery Corp.; PDF on discoverbattery.com captured on October 23, 2026) lists AES-B-GC12-24V (24V / 2560 Wh) in its warranty table with a Workmanship Warranty Period of "5 years", printed as one cell spanning all four listed models (AES-B-G24-12V-H, AES-B-G24-24V, AES-B-GC12-12V-H and AES-B-GC12-24V), an Annual Energy Throughput Limit of 1590 kWh and a Total Energy Throughput Limit of 4.7 MWh (the two throughput cells are printed across AES-B-GC12-12V-H and AES-B-GC12-24V). It prints that Discover "warrants to the original product purchaser (User), that your Lithium BLUE Premium Lithium Battery (Battery) is free from manufacturing defects that would prevent the battery from delivering unlimited cycles while maintaining at least 60% of the original Rated Wh for the earlier of the listed ‘Workmanship Warranty Period’ or ‘Total Energy Throughput Limit’." The warranty is headed "NON-TRANSFERABLE LIMITED PERFORMANCE WARRANTY"; the period is "the total period in years from the initial installation date"; registration is printed as optional ("Optional Registration at https://www.discoverlithium.com."). The warranty is void if the battery "surpasses the Annual Energy Throughput Limit in any 12-month period" or "is used in a Stationary Renewable Energy Storage application with a nominal voltage greater than 24VDC", among the other listed exclusions; a credit or refund after a claim covers the unused years of the period. "This Limited Warranty is effective for sales of Batteries occurring after June 24th, 2025."
Where: Lithium BLUE Warranty Policy 885-0063 REV A, page 1 table (Workmanship Warranty Period)
Captured by scripts/prepare-brand-sweep-sep21.mjs on 2026-09-28.
Location: Cover page (model list) and specification tables
Retrieved Sep 28, 2026
Discover Energy Systems' own installation and operation manual, captured September 28, 2026 with scripts/research/fetch.mjs from discoverbattery.com. Its cover page names battery models AES-B-G24-12V-H (900-0072), AES-B-G24-24V (900-0073), AES-B-GC12-12V-H (900-0075) and AES-B-GC12-24V (900-0076), and its specification tables carry each model's own ratings. Manufacturer instructions, not independent tests.
Archived copies
Archived copy of a document published by Discover Energy Systems. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Location: Page 1, warranty statement and table; page 5, Applicable Law and Effective Period
Retrieved Oct 23, 2026
Discover's own warranty policy PDF, published on discoverbattery.com and captured on Oct 23, 2026. The guarantor printed is Discover Battery Corp.; printed revision 885-0063 REV A. Its table names four models: AES-B-G24-12V-H, AES-B-G24-24V, AES-B-GC12-12V-H and AES-B-GC12-24V. It prints no publication date; it is effective for sales after June 24, 2025.
Archived copies
Archived copy of a document published by Discover. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Discover publishes no separate per-model datasheet PDF for this model; the product page is the specification sheet.
Location: Model AES-B-GC12-24V; first MECHANICAL and ELECTRICAL specification blocks
Retrieved Sep 18, 2026
Manufacturer-operated per-model product page, captured with a plain HTTPS GET and a desktop user agent; the page carries the specification tables Discover publishes for this exact model and terminal, and its "Download" control renders the same page client-side. It establishes what Discover published at this URL on the access date only: no revision history, no issuer verification of the standards it names, and no value on it was applied to any other model.
Archived copy of a document published by Discover. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Archived copy of a document published by Discover. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Archived copy of a document published by Discover. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Archived copy of a document published by Discover. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Lithium BLUE Installation and Operation Manual, 805-0083 Rev C
Archived copy of a document published by Discover Energy Systems. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Discover Lithium BLUE Warranty Policy, 885-0063 REV A (captured October 23, 2026)
Archived copy of a document published by Discover. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
No sourced accessories or replacement parts listed yet.
Model history
Model identity
Model
AES-B-GC12-24V
Observed Sep 18, 2026
UN 38.3: claimed
Battery pack claim; verification pending. Discover's own product page for AES-B-GC12-24V names "UN 38.3" in its certification block. This is a manufacturer statement recorded against that exact model page: no issuer listing, certificate number, edition, scope or validity was checked, and the lead-acid pages word it as designed in accordance with the standard rather than as a certification.
note: No qualifying applicable evidence recorded. This is not proof that certification is absent. Applies: UL 1973; CEC not applicable to 12 V / 24 V / 36 V DC modules; UL 9540 not applicable to 12 V / 24 V / 36 V DC modules.
