W 500 × H 260 × L 841.5 mm / W 19.7 × H 10.2 × L 33.13 in converted
Printed as "Dimension 33.13*19.69*10.24 in/84.15*50*26 cm" in the manual; the centimeter figures are converted to millimeters in the printed order. The store listing prints the same figures.
Where: PowerMega 314 user manual (Version 2.0), section 3.3.2 Parameters, PDF page 12
Printed as "Use the M8 screws on the battery to fix the battery connection wire" in the Powermega_314_V2_Battery_User_Manual_compressed_1.pdf (page 34, 6.2.2 DC power cable connection).
Where: PDF page 34, 6.2.2 DC power cable connection
When packs are used in parallel, set a different address on each pack with the BMS DIP switch; avoid setting the same address
Printed as "different PACKs can be distinguished by setting the address through the dip switch"; "It is necessary to avoid setting the address to the same." in the Powermega_314_V2_Battery_User_Manual_compressed_1.pdf (page 17, 3.3.3.1 ADD).
The manual prints "The BMS features active balancing" and, in its Cell Balance row, "Active Blance" (spelled as printed); the listing title prints "Active Balance".
Where: PowerMega 314 user manual (Version 2.0), section 3.2 Features, PDF page 11, and Cell Balance row, PDF page 14; AU store product data, listing "eco-worthy-48v-314ah-lifepo4-battery-solar-battery-backup-for-home-wall-mount", title
The manual and the store listing print different energy figures. The PowerMega 314 manual (Version 2.0) prints a nominal energy of 16.076KWh; the store listing prints "Battery Power: 16.08kWh". The manual figure is shown and the listing figure is kept beside it.
Printed as "Nominal energy 16.076KWh" in the manual, the primary source.
Where: PowerMega 314 user manual (Version 2.0), section 3.3.2 Parameters, PDF page 12
Sources
16.08 kWh
The store listing prints "Battery Power: 16.08kWh".
Printed as "Max. discharge current 200A(initial temp.≤35" (degrees Celsius) in the manual; the store listing prints "Max. discharge current:200A(initial temp.≤35 C)".
Where: PowerMega 314 user manual (Version 2.0), section 3.3.2 Parameters, PDF page 13
Printed as "Protocols supported by CAN *PYLON CAN Inverter EMS (Default) *Growatt CAN"; "*MEGAREVO CAN Inverter LV V1.1"; "Protocols supported by RS485 *PACE RS485 Modbus UN *PYLON RS485"; "*WOW RS485 Modbus V1.3-2017.06.27 *Schneider V2.0" in the Powermega_314_V2_Battery_User_Manual_compressed_1.pdf (page 23, 3.7.5 Supported communication protocols). The manual prints a version for each protocol; the names are recorded without the versions.
Where: PDF page 23, 3.7.5 Supported communication protocols
External disconnection breaker between the battery system and the inverter, chosen for the inverter power/current, rated voltage and tripping characteristic
Printed as "an external disconnection breaker between battery system and inverteris recommended."; "Choose the suitable disconnection breaker considering the inverterpower/current, rated voltage, and tripping characteristic etc." in the Powermega_314_V2_Battery_User_Manual_compressed_1.pdf (page 34, 6.3 Connecting with inverter).
Printed as "Rated voltage Max. voltage range Charge voltage" with the values "51.2V 40~58.4V 58.4V 40.0V" in the Powermega_314_V2_Battery_User_Manual_compressed_1.pdf (page 13, 3.3.2 Parameters). The labels and values run in the same order in the text layer: rated voltage 51.2 V, maximum voltage range 40 to 58.4 V, charge voltage 58.4 V.
Where: PDF page 13, 3.3.2 Parameters, Charge voltage row
Printed as "Supports RS-485 and CAN interfaces, ensuring smooth integration with mainstream inverter protocols." in the Powermega_314_V2_Battery_User_Manual_compressed_1.pdf (page 11, 3.2 Features, Seamless Compatibility).
Where: PDF page 11, 3.2 Features, Seamless Compatibility
Printed as "The battery is equipped with Bluetooth/WiFi capabilities for real-time monitoring" in the Powermega_314_V2_Battery_User_Manual_compressed_1.pdf (page 11, 3.2 Features, Smart Monitoring).
Where: PDF page 11, 3.2 Features, Smart Monitoring
No reviews. Be the first to review this product: Write a review
Sellers
No listed sellers in this data.
Price history
No seller price history.
Evidence score
13/100Missing details20% documented
The Evidence score uses the priorities you choose. It counts published documents, such as certificates and warranty terms, and it compares a documented figure with the best documented figure of the same kind. It does not count owner reviews, and it is not a verdict on product quality or on how many people have reviewed it. A low score can mean little is documented, or that a documented figure is below the best of its kind. Undisclosed data scores 0.
Missing details. This number counts only the evidence recorded so far. The source review for this product is not finished, or the maker has not disclosed enough, so the number can only go up.
Missing for this product: Certificates evidence needed; Warranty energy disclosure evidence needed; Lifetime / capacity evidence needed; Cell model disclosure evidence needed.
48 V · Format not recorded · Rated capacity
The warranty term and the lifetime energy are each scored against the best documented value for a home storage battery: a value earns its share of that best, times the weight. A documented value always earns points; an undisclosed one earns 0.
Printed as "[Premium Cells & 10-Year Warranty] Built with dedicated 314Ah A-Grade cells engineered for home storage, backed by a 10-year warranty for long-term reliability." in the description of ECO-WORTHY's Australian product page for the PowerMega 314 (au.eco-worthy.com, variant SKU AU-L13L314AHPMS-1), captured on September 29, 2026. The store-wide buy-box line "Up To 10-Year Warranty" and the FAQ answer "We provide up to a 10-year warranty on key battery models" are not used. The page names no start date, registration requirement, transfer terms, cycle or throughput limit or capacity retention for this term.
Research pending, 0 points: Certificates, Warranty energy disclosure, Cell model disclosure.
Computed from public specifications and evidence records. Warranty duration is not service quality; certificate evidence points are not a safety rating. Compatibility and installation limits still apply.
What this shows: what each record says and how far it reaches. It does not mean the product is approved.
Unknown: no certification evidence recorded in this data.
Warranty
Field
Value
Conditions
Source
Warranty term
10 years
Printed as "[Premium Cells & 10-Year Warranty] Built with dedicated 314Ah A-Grade cells engineered for home storage, backed by a 10-year warranty for long-term reliability." in the description of ECO-WORTHY's Australian product page for the PowerMega 314 (au.eco-worthy.com, variant SKU AU-L13L314AHPMS-1), captured on September 29, 2026. The store-wide buy-box line "Up To 10-Year Warranty" and the FAQ answer "We provide up to a 10-year warranty on key battery models" are not used. The page names no start date, registration requirement, transfer terms, cycle or throughput limit or capacity retention for this term.
Original manufacturer-hosted PDF preserved byte for byte, downloaded from the link published on ECO-WORTHY's own product page for SKU GW-L03L314AHJC-1. The revision is whatever was served at this URL on the access date; no later revision was checked, no issuer or laboratory record was read against anything the document states, and no coverage is claimed beyond the SKU whose page linked it.
Archived copy of a document published by ECO-WORTHY. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
ECO-WORTHY's own product page for the listing "eco-worthy-48v-314ah-lifepo4-battery-solar-battery-backup-for-home-wall-mount" on au.eco-worthy.com (Australia), captured September 29, 2026. Cited for the documents its download section links (checked in the page markup). Manufacturer claims, not independent tests.
Archived copy of a document published by ECO-WORTHY. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Order: products a manufacturer names first, then by Evidence score at default weights.
Matched on printed specifications only: each manufacturer's datasheet, as recorded on the product pages. A match means one product's printed figure falls inside the other's printed limit. It does not mean the two have been shown to work together. A figure a manufacturer does not print shows as Not documented and is never assumed. This is not a test or an approval. A qualified installer and the local code decide what can be connected.
Parts and accessories
No sourced accessories or replacement parts listed yet.
Model history
Model identity
Model
ECO-LFP4831400-V2
Manufacturer SKU AU-L13L314AHPMS-1 · AU market
No historical observations recorded yet.
Other recorded fields
Field
Value
Conditions
Source
Evidence breakdown
method version: 0.21-personal
documented pct: 20
basis: nominal
missing:
Certificates evidence needed
Warranty energy disclosure evidence needed
Lifetime / capacity evidence needed
Cell model disclosure evidence needed
criteria:
key: certificateEvidence
label: Certificates
value: 0
unit: evidence points
shown: Research pending
shown detail: Unknown
state: pending
points: 0
ceiling: 45
weight: 45
share: 0
covered: no
missing: yes
folded: yes
reason: Unknown
reason text: Unknown
note: No qualifying applicable evidence recorded. This is not proof that certification is absent. Applies: CEC; UL 9540; UL 1973.
