Printed as "Cell Type LFP (LiFePO4)" in the GoodWe Lynx Home A G3 datasheet (footer dated 2025-07-25, V2.1), Battery system table, one value printed for every model in the table, captured on September 25, 2026.
Where: GoodWe Lynx Home A G3 datasheet, Technical Data, Battery system table, merged cell
Printed as "Weight (kg) 44" in the GoodWe Lynx Home A G3 datasheet (footer dated 2025-07-25, V2.1), General data table, one value printed for every model in the table, captured on September 25, 2026.
Where: GoodWe Lynx Home A G3 datasheet, Technical Data, General data table, merged cell
W 442 × H 133 × D 520 mm / W 17.4 × H 5.24 × D 20.5 in converted
Printed as "Dimensions (W × H × D mm) 442 × 133 × 520 (Excluding hanger) 483 × 133 × 559 (Including hanger)" in the GoodWe Lynx Home A G3 datasheet (footer dated 2025-07-25, V2.1), captured on September 25, 2026. Recorded without the hanger; with the hanger the datasheet prints 483 × 133 × 559 mm.
Charged Reviews classified this product from the documents it is based on. It is our own grouping, not a manufacturer claim.
Printed as "Mounting Method 19-inch standard rack, Floor-mounted, Wall-Mounted" in the GoodWe Residential Smart Inverter Solutions User Manual (ET-LV series), 10.2.1 LX A5.0-30, captured September 27, 2026. Classified as "rack" (server rack format) since the manual names "19-inch standard rack" first among the supported mounting methods.
Printed as "Max. Continuous Discharge Power (W) 7200 Communication CAN" in the GoodWe Residential Smart Inverter Solutions User Manual (ET-LV series, EN) (page 422, 10.2.1 LX A5.0-30 Technical Parameters, Communication row).
Where: PDF page 422, 10.2.1 LX A5.0-30 Technical Parameters, Communication row
Printed as "Ingress Protection Rating IP20" in the GoodWe Lynx Home A G3 datasheet (footer dated 2025-07-25, V2.1), General data table, one value printed for every model in the table, captured on September 25, 2026.
Where: GoodWe Lynx Home A G3 datasheet, Technical Data, General data table, merged cell
Printed as "Nominal Charge Current (A) *2 60" in the GoodWe Residential Smart Inverter Solutions User Manual (ET-LV series, EN) (page 422, 10.2.1 LX A5.0-30 Technical Parameters, Nominal Charge Current row). Printed as the nominal charge current; footnote *2: working current and power relate to temperature and SOC.
Where: PDF page 422, 10.2.1 LX A5.0-30 Technical Parameters, Nominal Charge Current row
COM1 and COM2: inverter communication (CAN) or battery parallel/cluster communication
Printed as "LX A5.0-30 Communication Port Definition PIN COM1 COM2"; "Connects to inverter communication or battery parallel cluster communication port" in the GoodWe Residential Smart Inverter Solutions User Manual (ET-LV series, EN) (page 141, 5.8 Connecting the Battery Cable, LX A5.0-30 Communication Port Definition table).
Where: PDF page 141, 5.8 Connecting the Battery Cable, LX A5.0-30 Communication Port Definition table
Charging range, printed as "Operating Temperature (°C) Charge: 0<T≤55 Discharge: -20<T≤55" in the GoodWe Lynx Home A G3 datasheet (footer dated 2025-07-25, V2.1), captured on September 25, 2026.
Printed as "Max. Continuous Discharge Power (W) 7200" in the GoodWe Residential Smart Inverter Solutions User Manual (ET-LV series, EN) (page 422, 10.2.1 LX A5.0-30 Technical Parameters, Max. Continuous Discharge Power row). Footnote *3: max charge/discharge current and power values may vary with different inverter models.
Where: PDF page 422, 10.2.1 LX A5.0-30 Technical Parameters, Max. Continuous Discharge Power row
Printed as "Nominal Discharge Current (A) *2 100" in the GoodWe Residential Smart Inverter Solutions User Manual (ET-LV series, EN) (page 422, 10.2.1 LX A5.0-30 Technical Parameters, Nominal Discharge Current row). Printed as the nominal discharge current; footnote *2: working current and power relate to temperature and SOC.
Where: PDF page 422, 10.2.1 LX A5.0-30 Technical Parameters, Nominal Discharge Current row
Discharging range, printed as "Operating Temperature (°C) Charge: 0<T≤55 Discharge: -20<T≤55" in the GoodWe Lynx Home A G3 datasheet (footer dated 2025-07-25, V2.1), captured on September 25, 2026.
Printed as "CAN communication is used between the inverter and the battery." in the GoodWe Residential Smart Inverter Solutions User Manual (ET-LV series, EN) (page 141, 5.8 Connecting the Battery Cable, BMS communication table). The inverter BMS port connects to the battery COM1 port (pins 4 CAN_H and 5 CAN_L).
Where: PDF page 141, 5.8 Connecting the Battery Cable, BMS communication table
30.57 L* (Calculated enclosure volume: W × H × D in mm ÷ 1,000,000)W: 442 × H: 133 × D: 520 mm / W: 17.4 × H: 5.24 × D: 20.5 in44 kg / 97 lb0.17 kWh/L* (Rated or usable capacity shown on this card ÷ enclosure volume)
Evidence score
7/100Missing details20% documented
The Evidence score uses the priorities you choose. It counts published documents, such as certificates and warranty terms, and it compares a documented figure with the best documented figure of the same kind. It does not count owner reviews, and it is not a verdict on product quality or on how many people have reviewed it. A low score can mean little is documented, or that a documented figure is below the best of its kind. Undisclosed data scores 0.
Missing details. This number counts only the evidence recorded so far. The source review for this product is not finished, or the maker has not disclosed enough, so the number can only go up.
Missing for this product: Certificates evidence needed; Warranty energy disclosure evidence needed; Lifetime / capacity evidence needed; Cell model disclosure evidence needed.
Server rack · Rated capacity
The warranty term and the lifetime energy are each scored against the best documented value for a home storage battery: a value earns its share of that best, times the weight. A documented value always earns points; an undisclosed one earns 0.
Product warranty on the electronics and enclosure, printed as "1. 5 years of product warranty: GOODWE warrants that the hardware of electronics and enclosure" in the GOODWE Limited Warranty for Lynx Series LX A 5.0-30 Battery System (Rev: 1.0 20240925), captured on September 25, 2026. The policy's Geographical Scope clause limits it to devices bought from authorized channels and installed in the international market it defines, which excludes the regions GoodWe covers with separate terms (the United States and Canada among them).
Research pending, 0 points: Certificates, Cell model disclosure.
Computed from public specifications and evidence records. Warranty duration is not service quality; certificate evidence points are not a safety rating. Compatibility and installation limits still apply.
What this shows: what each record says and how far it reaches. It does not mean the product is approved.
Unknown: no certification evidence recorded in this data.
Warranty
Field
Value
Conditions
Source
Retention
70 %
Performance warranty, printed as "GOODWE warrants that, for ten (10) years, the battery system retains either seventy percent (70%) of Usable Energy" in the GOODWE Limited Warranty for Lynx Series LX A 5.0-30 Battery System (Rev: 1.0 20240925), captured on September 25, 2026: 70% of usable energy for ten years or until the minimum throughput, whichever comes first. The performance warranty term (10 years) differs from the product warranty term.
Global-market policy; not the United States or Canada
Product warranty on the electronics and enclosure, printed as "1. 5 years of product warranty: GOODWE warrants that the hardware of electronics and enclosure" in the GOODWE Limited Warranty for Lynx Series LX A 5.0-30 Battery System (Rev: 1.0 20240925), captured on September 25, 2026. The policy's Geographical Scope clause limits it to devices bought from authorized channels and installed in the international market it defines, which excludes the regions GoodWe covers with separate terms (the United States and Canada among them).
Minimum Through Output Energy, printed as "LX A5.0-30 5.0 15" in the GOODWE Limited Warranty for Lynx Series LX A 5.0-30 Battery System (Rev: 1.0 20240925), captured on September 25, 2026.
Captured by scripts/prepare-brand-sweep-sep21.mjs on 2026-09-27.
Location: 10.2 Battery Technical Data
Retrieved Sep 27, 2026
GoodWe's own combined installation and operation manual for the ET-LV series residential system, captured from en.goodwe.com on September 27, 2026. Section 10.2 Battery Technical Data documents LX A5.0-30, LX U5.0-30, GW14.3-BAT-LV-G10 and GW16.1-BAT-LV-G10 directly.
Archived copies
Archived copy of a document published by GoodWe. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Captured by scripts/prepare-brand-sweep-sep21.mjs on 2026-09-25.
Location: Technical Data table, one column per model
Retrieved Sep 24, 2026
GoodWe family datasheet (Lynx Home A G3), fetched from en.goodwe.com (the file the series page en.goodwe.com/lynxa-g3-series links as "Datasheet") and archived on September 25, 2026. Its Technical Data table sets the models side by side, one column per model, so each figure is read from the named model column and the whole row is quoted; a value printed once spans every column. It names models, not ordering SKUs. It is a manufacturer claim; no figure was tested independently.
Archived copies
Archived copy of a document published by GoodWe. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Captured by scripts/prepare-brand-sweep-sep21.mjs on 2026-09-25.
Location: Overview and Geographical Scope
Retrieved Sep 24, 2026
GoodWe limited warranty naming the Lynx battery system LX A5.0-30. Fetched from en.goodwe.com (linked from en.goodwe.com/warranty) and archived on September 25, 2026. The policy's Geographical Scope clause limits it to devices bought from authorized channels and installed in the international market it defines, which excludes the regions GoodWe covers with separate terms (the United States and Canada among them). It is the manufacturer's published policy, not a purchaser-specific contract.
Archived copies
Archived copy of a document published by GoodWe. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Earlier revisions, archived captures and copies published by someone other than the manufacturer. Every one stays reachable.
Archived documents
GoodWe Lynx Home A G3 datasheet (GoodWe-Single page-20250725-EN-V2.1)
Archived copy of a document published by GoodWe. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
GOODWE Limited Warranty for Lynx Series LX A 5.0-30 Battery System, Rev: 1.0 20240925
Archived copy of a document published by GoodWe. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
GoodWe Residential Smart Inverter Solutions User Manual (ET-LV series, EN)
Archived copy of a document published by GoodWe. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
No sourced accessories or replacement parts listed yet.
Model history
Model identity
Model
LX A5.0-30
No historical observations recorded yet.
Other recorded fields
Field
Value
Conditions
Source
Evidence breakdown
method version: 0.21-personal
documented pct: 20
basis: nominal
missing:
Certificates evidence needed
Warranty energy disclosure evidence needed
Lifetime / capacity evidence needed
Cell model disclosure evidence needed
criteria:
key: certificateEvidence
label: Certificates
value: 0
unit: evidence points
shown: Research pending
shown detail: Unknown
state: pending
points: 0
ceiling: 45
weight: 45
share: 0
covered: no
missing: yes
folded: yes
reason: Unknown
reason text: Unknown
note: No qualifying applicable evidence recorded. This is not proof that certification is absent. Applies: UL 1973; CEC not assessed without a documented voltage class; UL 9540 not assessed without a documented voltage class.
