Printed as "Frame Anodized Aluminum (Silver)" in Silfab Solar SIL-620/630/640 XL BIFACIAL datasheet, captured on September 28, 2026. The domestic-content suffix on this catalog model is a sourcing declaration, not a separate construction; the datasheet names the same base model.
A UL listed grounding lug can be bonded to the grounding hole located on the bottom flange of Silfab Solar’s module frame.; The grounding lug should be attached to the frame grounding hole using stainless steel hardware (bolt, serrated flange nut, toothed lock washer, KEPS nut, etc).; Silfab Solar modules may be bonded to a racking or rail system using an integrated grounding method certified to UL 2703.
Printed as "A UL listed grounding lug can be bonded to the grounding hole located on the bottom flange of Silfab Solar’s module frame." under Option A in Silfab Solar's Safety and Installation Manual for Photovoltaic Modules (MAN-SSI-13, April 29, 2026), section 9.3 Protective Grounding; Option B allows an integrated grounding method certified to UL 2703. Instruction for all Silfab Solar modules the manual covers.
Where: PDF page 20, section 9.3 Protective Grounding, Option A and Option B
3.2 mm high transmittance, tempered, antireflective coating
Printed as "Glass 3.2 mm high transmittance, tempered, antireflective coating" in Silfab Solar SIL-620/630/640 XL BIFACIAL datasheet, captured on September 28, 2026. The domestic-content suffix on this catalog model is a sourcing declaration, not a separate construction; the datasheet names the same base model.
High durability, superior hydrolysis and UV resistance, multi-layer dielectric film, transparent PV backsheet
Printed as "Backsheet High durability, superior hydrolysis and UV resistance, multi-layer dielectric film, transparent PV backsheet" in Silfab Solar SIL-620/630/640 XL BIFACIAL datasheet, captured on September 28, 2026. The domestic-content suffix on this catalog model is a sourcing declaration, not a separate construction; the datasheet names the same base model.
LONG EDGE MOUNTING L Design Load Test Load 175 - 500 +800 / -666 +1200 / -1000 500 - 625 +1466 / -1466 +2200 / -2200; LONG EDGE MOUNTING WITH CENTER SUPPORT L Design Load Test Load 0 - 175 +1800 / -1600 +2700 / -2400 175 - 400 +1800 / -1600 +2700 / -2400; SHORT EDGE MOUNTING WITH CENTER SUPPORT L Design Load Test Load 0 - 300 +2000 / -2000 +3000 / -3000; SHORT EDGE PARALLEL TO RAILS L Design Load Test Load 450 - 475 +3600 / - 1600 +5400 / - 2400 475 - 625 +2400 / - 1600 +3600 / - 2400; LONG EDGE PARALLEL TO RAILS L Design Load Test Load 450 - 550 +1466 / -1466 +2200 / -2200; LONG EDGE TRACKER MOUNTING L Design Load Test Load 400 +1066 / -1066 +1600 / -1600 1400 +1466 / -1466 +2200 / -2200 400 + 1400 +1600 / -1600 +2400 / -2400; M6 or 1/4” corrosion-resistant bolts, nuts, and a locking feature are required; are permitted for the following Silfab Solar product lines: SIL-XXX BK/BG/HC/HC+/QD/HN/HM/QM/XM/ XM+/XL.
Printed as "RAIL-LESS MOUNTING SYSTEMS FOR SIL XL" (table heading) with the first row printed as "LONG EDGE MOUNTING L Design Load Test Load 175 - 500 +800 / -666 +1200 / -1000 500 - 625 +1466 / -1466 +2200 / -2200" on PDF page 17 and 18 of Silfab Solar's Safety and Installation Manual for Photovoltaic Modules (MAN-SSI-13, April 29, 2026): each listed line is one printed table row or table (configuration name, clamp position L in millimeters, design load and test load in pascals; positive values downward, negative values uplift). The manual prints both design and test loads and they differ by mounting method, so no single front or rear design load is recorded for this model. Section 8.2 (PDF page 4) prints the bolt requirement for the factory mounting holes and section 8.3 (PDF page 5) permits rear flange-mounted clamps for the series lines it lists, including SIL-XXX XL.
Where: PDF page 17 and 18, mounting tables for SIL XL; PDF page 4 and 5, sections 8.2 and 8.3
Cable bending radius should be at least 60 mm (2 3/8”).
Printed as "Cable bending radius should be at least 60 mm (2 3/8”)." in Silfab Solar's Safety and Installation Manual for Photovoltaic Modules (MAN-SSI-13, April 29, 2026), section 9.1 Electrical Connection; section 7 Safety Precautions (PDF page 4) also says "maintaining a minimum bending radius of 60 mm (2 3/8”) at all locations along the cable." Instruction for all Silfab Solar modules the manual covers.
Where: PDF page 19, section 9.1 Electrical Connection; PDF page 4, section 7 Safety Precautions
Printed as "For SIL-XXX XM/XM+/XL, the maximum series fuse rating is 30A." in Silfab Solar's Safety and Installation Manual for Photovoltaic Modules (MAN-SSI-13, April 29, 2026), section 9.1 Electrical Connection, the sentence that names this model's series. Series-level rating.
Where: PDF page 19, section 9.1 Electrical Connection
Printed as "For SIL-XXX HN/HM/ QM/XM/XM+/XL, the maximum system voltage rating is 1500V." in Silfab Solar's Safety and Installation Manual for Photovoltaic Modules (MAN-SSI-13, April 29, 2026), section 9.1 Electrical Connection, the sentence that names this model's series. Series-level rating. Re-cited on 1 October 2026 to the manufacturer's own document; previously cited to Greentech Renewables (greentechrenewables.com), which stays listed as an additional source.
Where: PDF page 19, section 9.1 Electrical Connection
Printed as "22.56%" in the cdn.myced.com manufacturer datasheet (PDF), Silfab data sheet, page 2, Electrical Specifications, Module efficiency (STC), 630 W column. Revised on 1 October 2026: The Silfab data sheet for this module prints a module efficiency of 22.56% at STC, matching the record, and a maker data sheet outranks the seller listing now cited.
Where: Silfab data sheet, page 2, Electrical Specifications, Module efficiency (STC), 630 W column
Printed as "-0.29 %/°C" in the cdn.myced.com manufacturer datasheet (PDF), Silfab data sheet, page 2, Temperature Ratings, Temperature Coefficient Pmax. Revised on 1 October 2026: The Silfab data sheet for this module prints a Pmax temperature coefficient of -0.29 %/°C, matching the record, and a maker data sheet outranks the seller listing now cited.
Where: Silfab data sheet, page 2, Temperature Ratings, Temperature Coefficient Pmax
Printed as "Temperature Coefficient Voc -0.24 %/°C" in View. The datasheet is the model family's sheet this record already cites; it prints one Voc temperature coefficient for every model it lists.
Where: Specification table, temperature coefficients
The Evidence score uses the priorities you choose. It counts published documents, such as certificates and warranty terms, and it compares a documented figure with the best documented figure of the same kind. It does not count owner reviews, and it is not a verdict on product quality or on how many people have reviewed it. A low score can mean little is documented, or that a documented figure is below the best of its kind. Undisclosed data scores 0.
Missing for this product: Product warranty needed; Power warranty needed; First-year degradation needed; Weight / watt needed.
Each input is scored against the best documented value for a solar panel, and weight per watt against the best in the panel’s own format. A documented value always earns points; an undisclosed one earns 0 and is listed as missing. Certificates and unsupported claims do not add points.
Printed as "22.56%" in the cdn.myced.com manufacturer datasheet (PDF), Silfab data sheet, page 2, Electrical Specifications, Module efficiency (STC), 630 W column. Revised on 1 October 2026: The Silfab data sheet for this module prints a module efficiency of 22.56% at STC, matching the record, and a maker data sheet outranks the seller listing now cited.
Power temperature coefficient-0.29 %/°C12.1 / 16.0
0.29 against 0.22 %/°C, the lowest documented for a solar panel (printed by the maker): Jackery SolarSaga 100 Air
Printed as "-0.29 %/°C" in the cdn.myced.com manufacturer datasheet (PDF), Silfab data sheet, page 2, Temperature Ratings, Temperature Coefficient Pmax. Revised on 1 October 2026: The Silfab data sheet for this module prints a Pmax temperature coefficient of -0.29 %/°C, matching the record, and a maker data sheet outranks the seller listing now cited.
