Option A: Use of a grounding lug. A listed grounding lug can be bonded to the frame using the grounding holes pre-drilled in the frame.; The grounding lug should be attached to the frame grounding hole using a stainless steel screw, toothed lock washer or KEPS nut (in order to penetrate the anodized layer) and backing nut.; Option B: Integrated grounding methods. The Q CELLS modules can be bonded with the racking system using UL61730 or UL2703 certified integrated grounding methods.
Printed as "A listed grounding lug can be bonded to the frame using the grounding holes pre-drilled in the frame." in Qcells' Installation and Operation Manual for Q.PEAK DUO XL-G10.X / BFG and XL-G10.X / BGT solar modules (North America, document revision 01, 2021), section 5 Grounding, Option A (grounding lug, stainless steel or tin plated, through the frame grounding holes of 0.177 in) and Option B (integrated grounding, for example WEEB washers). The frame and all non-current-carrying metal parts must be grounded (NEC Article 250).
Where: PDF page 12, section 5 Grounding (Option A and Option B)
Printed as "Weight [lbs] 64.2 (29.1 kg)" in Qcells' Installation and Operation Manual for Q.PEAK DUO XL-G10.X / BFG and XL-G10.X / BGT solar modules (North America, document revision 01, 2021), section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT). The kilogram figure printed in brackets. Revised on 1 October 2026: Owner source order puts the installation manual first: Qcells' installation manual for the Q.PEAK DUO XL-G10.X / BFG series prints 29.1 kg; the earlier value 29.1206 kg came from a seller product page (Greentech Renewables) and is kept beside it.
Where: PDF page 3, section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT)
Sources
29.1 kg
Seller-listed specification; not independently verified.
0.08 in (2.0 mm) thermally pre-stressed glass with anti-reflection technology
Printed as "Front Cover 0.08 in (2.0 mm) thermally pre-stressed glass with anti-reflection technology" in Qcells' Q.PEAK DUO XL-G10.3/BFG 475-490 datasheet, captured on September 28, 2026.
Where: Page 2, MECHANICAL SPECIFICATION, Front Cover row
W 1,045 × L 2,216 × D 35 mm / W 41.14 × L 87.24 × D 1.4 in converted
Printed as "Length [in] 87.2 (2216 mm) Width [in] 41.1 (1045 mm) Frame height [in] 1.38 (35 mm)" in Qcells' Installation and Operation Manual for Q.PEAK DUO XL-G10.X / BFG and XL-G10.X / BGT solar modules (North America, document revision 01, 2021), section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT). The millimeter figures printed in brackets. Re-cited on 1 October 2026 to the manufacturer's own document; previously cited to Greentech Renewables (greentechrenewables.com), which stays listed as an additional source.
Where: PDF page 3, section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT)
CL1a, clamps at 11.8 - 21.6 in (300 - 550 mm): test load push / pull 5400 / 3000 Pa, design load push / pull 3600 / 2000 Pa; CL1b, clamps at 11.8 - 21.6 in (300 - 550 mm): test load 2900 / 3000 Pa, design load 1930 / 2000 Pa; FB1, mounting slots at 17.9 in (454 mm): test load 5400 / 3000 Pa, design load 3600 / 2000 Pa; FB2 and mFB2, mounting slots at 17.9 in (454 mm), and CL3, clamps at 11.8 - 21.6 in (300 - 550 mm): test load 3600 / 3000 Pa, design load 2400 / 2000 Pa; mCL3, clamps at 11.8 - 21.6 in (300 - 550 mm): test load 3300 / 3000 Pa, design load 2200 / 2000 Pa; CL5, short side 0.8 - 3.9 in (20 - 100 mm), long side 19.7 - 23.6 in (500 - 600 mm): test load 2400 / 2400 Pa, design load 1600 / 1600 Pa; Tracker options: TB1b and TB2b 3000 / 3000 Pa (design 2000 / 2000 Pa); TB1a 2400 / 2400 Pa (design 1600 / 1600 Pa); TB2a 2700 / 2400 Pa (design 1800 / 1600 Pa); TC1 2200 / 2200 Pa (design 1460 / 1460 Pa); Only under certain conditions: CL1a at 0.8 - 21.6 in (20 - 550 mm) 2000 / 2000 Pa (design 1330 / 1330 Pa); CL2b at 0.8 - 3.9 in (20 - 100 mm) 1600 / 1600 Pa (design 1060 / 1060 Pa)
Printed as "CL1a 11.8 - 21.6 (300 - 550) 5400 / 3000 3600 / 2000 1.5" in Qcells' Installation and Operation Manual for Q.PEAK DUO XL-G10.X / BFG and XL-G10.X / BGT solar modules (North America, document revision 01, 2021), section 2.3 Mounting Options: each mounting option with the position of clamps (distance from the outer edge of the module to the middle of the clamp, in inches with millimeters in brackets), test load push / pull and design load push / pull in Pa, safety factor 1.5. Rows that share one load cell (FB2, mFB2 and CL3; TB1b and TB2b) were grouped as read from rendered page 6. The last two options do not fulfill the requirements of the standards, as the table footnote states. Clamps: width at least 1.5 in (38 mm), depth 0.2 - 0.47 in (5 - 12 mm); tighten clamps and screws according to the manufacturer's instructions (no torque is printed).
Where: PDF page 6, section 2.3 Mounting Options, Specifications table (with Fig. 2 on PDF page 5)
Printed as "Comply with bending radius of ≥ 2.36 in (60 mm)" in Qcells' Installation and Operation Manual for Q.PEAK DUO XL-G10.X / BFG and XL-G10.X / BGT solar modules (North America, document revision 01, 2021), section 4.3 Connection of modules. Printed in the note "Ensure that the cabling is not under mechanical stress".
Where: PDF page 11, section 4.3 Connection of modules
Printed as "Max. series fuse rating 20 A" in Qcells' Installation and Operation Manual for Q.PEAK DUO XL-G10.X / BFG and XL-G10.X / BGT solar modules (North America, document revision 01, 2021), section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT). One figure for the product line.
Where: PDF page 3, section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT)
Printed as "Junction box protection class ≥ IP67 with bypass diode" in Qcells' Installation and Operation Manual for Q.PEAK DUO XL-G10.X / BFG and XL-G10.X / BGT solar modules (North America, document revision 01, 2021), section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT). Printed with "≥" (at least IP67).
Where: PDF page 3, section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT)
Printed as "Max. system voltage VSYS 1500 V (IEC) / 1500 V (UL)" in Qcells' Installation and Operation Manual for Q.PEAK DUO XL-G10.X / BFG and XL-G10.X / BGT solar modules (North America, document revision 01, 2021), section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT). The same 1500 V for the IEC and UL ratings, one figure for the product line. Re-cited on 1 October 2026 to the manufacturer's own document; previously cited to Greentech Renewables (greentechrenewables.com), which stays listed as an additional source.
Where: PDF page 3, section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT)
Distributor figure is the bifacial (BSTC) efficiency. The distributor listing prints 22.4% efficiency. Qcells' datasheet prints ≥ 20.5% at STC and ≥ 22.4% at BSTC, which includes rear-side light; the STC figure is the module rating.
Printed as "≥ 20.5" (a minimum, at STC) in the 475 STC column of the row "Efficiency1 η [%]" in Qcells' datasheet Q.PEAK DUO XL-G10.3 / BFG_475-490_2021-08_Rev01_NA; the BSTC column beside it prints "≥ 22.4". STC: 1000 W/m² front-side irradiance, 25 °C, AM 1.5. Revised on October 5, 2026: the earlier 22.4% came from a distributor listing and equals the datasheet's BSTC (bifacial) figure, which adds rear-side irradiance on top of STC; it is kept beside this value as an alternative.
Where: Datasheet page 2, Minimum Performance at Standard Test Conditions table, Efficiency row, power class 475 STC column
Sources
22.4 %
Distributor listing figure, printed without a test condition. Qcells' datasheet prints ≥ 22.4% for this power class only at BSTC, which it defines as "1000 W/m² + φ × 135 W/m², φ = 70 % ± 5 %".
Printed as "Permissible temperature range –40 °F to +185 °F (–40 °C to +85 °C)" in Qcells' Installation and Operation Manual for Q.PEAK DUO XL-G10.X / BFG and XL-G10.X / BGT solar modules (North America, document revision 01, 2021), section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT). The Celsius figures printed in brackets.
Where: PDF page 3, section 2.1 Technical Specifications (product line Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG, XL-G10.d / BGT)
No reviews. Be the first to review this product: Write a review
Sellers
No listed sellers in this data.
Price history
No seller price history.
Evidence score
22/10031% documented
The Evidence score uses the priorities you choose. It counts published documents, such as certificates and warranty terms, and it compares a documented figure with the best documented figure of the same kind. It does not count owner reviews, and it is not a verdict on product quality or on how many people have reviewed it. A low score can mean little is documented, or that a documented figure is below the best of its kind. Undisclosed data scores 0.
Missing for this product: Product warranty needed; Power warranty needed; Power temperature coefficient needed; First-year degradation needed.
Each input is scored against the best documented value for a solar panel, and weight per watt against the best in the panel’s own format. A documented value always earns points; an undisclosed one earns 0 and is listed as missing. Certificates and unsupported claims do not add points.
Module efficiency20.5 %20.9 / 26.0
20.5 % is the less favorable figure the maker's documents print, and it is scored because they disagree; it never sets or raises the bar. The bar is 25.5 %, the best documented for a solar panel, printed by the maker: AIKO Comet 3N72 AIKO-A690-MDE72Mw 690W Mono-Glass Module
Printed as "≥ 20.5" (a minimum, at STC) in the 475 STC column of the row "Efficiency1 η [%]" in Qcells' datasheet Q.PEAK DUO XL-G10.3 / BFG_475-490_2021-08_Rev01_NA; the BSTC column beside it prints "≥ 22.4". STC: 1000 W/m² front-side irradiance, 25 °C, AM 1.5. Revised on October 5, 2026: the earlier 22.4% came from a distributor listing and equals the datasheet's BSTC (bifacial) figure, which adds rear-side irradiance on top of STC; it is kept beside this value as an alternative.
The maker's documents disagree; the less favorable printed figure, 20.5 %, is scored. Warning: Distributor figure is the bifacial (BSTC) efficiency
A green check means we found this model, with that standard, on the certifier's own listing, the test lab's own report, or the California Energy Commission's equipment list.
What this shows: what each record says and how far it reaches. It does not mean the product is approved.
StandardEvidenceStatusSource
CECauthority listing reportedlisted as of snapshot[5]
Scope
equipment listing
Covered models
Q.PEAK DUO XL-G10.3/BFG 475
Limitations
Model Q.PEAK DUO XL-G10.3/BFG 475 listed on the California Energy Commission PV Module List (data unchanged since October 1, 2026; downloaded October 11, 2026) under Qcells North America, as "Q.PEAK DUO XL-G10.3/BFG 475", CEC listing date 2021-07-21. This is an equipment listing, not UL certification or complete-system approval.
Location: PDF page 2 (introduction, validity) and PDF page 3 (2.1 Technical Specifications)
Retrieved Oct 1, 2026
Qcells' own installation and operation manual for the Q.PEAK DUO XL-G10.X / BFG and XL-G10.X / BGT series, valid for North America as of July 1st 2021 for Q.PEAK DUO XL-G10.3 / BFG, XL-G10.3 / BGT, XL-G10.d / BFG and XL-G10.d / BGT modules (introduction). Printed as document revision 01 (back page: 2021-06_Rev01_NA; the file name Qcells used reads 2021-07_Rev02_NA). Qcells no longer serves the file; captured 1 October 2026 as the Internet Archive copy of August 7, 2024 of the file us.qcells.com then served. It gives one technical specification block for the product line and series-level mounting, grounding and wiring instructions; electrical ratings are left to the data sheet. Manufacturer instructions, not independent tests.
ViewOfficial · cdn.myced.com · Official datasheet · PDFSource details
Revision
Not stated
Revision date
Not stated
Linked from the GreenTech Renewables product page with link text "View".
Location: ZZ304800184_DS.pdf
Retrieved Sep 18, 2026
Original PDF preserved byte for byte, found linked from the GreenTech Renewables listing https://www.greentechrenewables.com/product/qcells-475w-156-half-cell-1500v-silver-bifacial-solar-panel-qpeak-duo-xl-g103bfg-475. The revision is whatever was published at this URL on the access date; exact variant coverage inside the document was not separately verified and no later revision was checked.
Archived copy of a document published by cdn.myced.com. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Earlier revisions, archived captures and copies published by someone other than the manufacturer. Every one stays reachable.
Archived documents
Qcells Q.PEAK DUO XL-G10.3/BFG 475 datasheet
Archived copy of a document published by Qcells. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
No sourced accessories or replacement parts listed yet.
Model history
Model identity
Model
Q.PEAK DUO XL-G10.3/BFG 475
Manufacturer SKU Q.PEAK DUO XL-G10.3/BFG 475
Observed Oct 11, 2026
CEC: claimed
Product / system scope unresolved. Model Q.PEAK DUO XL-G10.3/BFG 475 listed on the California Energy Commission PV Module List (data unchanged since October 1, 2026; downloaded October 11, 2026) under Qcells North America, as "Q.PEAK DUO XL-G10.3/BFG 475", CEC listing date 2021-07-21. This is an equipment listing, not UL certification or complete-system approval.
reason text: The maker's documents disagree; the less favorable printed figure, 20.5 %, is scored. Warning: Distributor figure is the bifacial (BSTC) efficiency
