conditions: SnapNrack prints SKU 242-02073 on its own product page for this part and beside the description in its 2026 Product Catalog. Revised on 28 September 2026: No manufacturer SKU was recorded; SnapNrack's own page and catalog print it.
Read from the SnapNrack Product Catalog 2026 Q1 (v1.1), End Clamps table, which prints "Ultra Rail End Clamp, Black 242-02073". SnapNrack technical data sheet SNR-DC-01338 (rev B) prints "SKU COLOR 242-02072 SILVER 242-02073 BLACK". Re-cited on 25 September 2026 to the manufacturer's own document; previously cited to Signature Solar (signaturesolar.com), which stays listed as an additional source.
Where: SnapNrack Product Catalog 2026 Q1, End Clamps table
Printed as "6000 SERIES ALUMINUM, STAINLESS STEEL" in the MATERIALS cell of SnapNrack technical data sheet SNR-DC-01338 (rev B), captured on September 25, 2026.
Printed as "WEIGHT (LBS): 0.16" in the SnapNrack technical data sheet: Ultra Rail End Clamp (SNR-DC-01338, rev B); the maker prints pounds only, converted to kilograms. Revised on 30 September 2026: The maker prints this weight in pounds only; the stored kilograms were an unlabeled conversion, now labeled with the printed pounds kept (Project Manager, September 30, 2026).
Where: TDS SNR-DC-01338, WEIGHT (LBS) cell
Sources
Converted: 0.16 lb x 0.45359237 kg/lb, rounded to 0.01 kg
Printed as "16 FT-LBS" in the "TORQUE SPECIFICATION:" row in SnapNrack's SNR DC 01338 SNAPNRACK TDS ULTRA RAIL END CLAMP (PDF page 1). The manual applies to this model: Technical data sheet SNR_DC_01338_SNAPNRACK_TDS_ULTRA_RAIL_END_CLAMP names part number(s) 242-02072, 242-02073 in its PART NUMBER(S) title block. The rendered drawing pairs the row label and the value, which the text layer prints apart.
Printed as "SNAPNRACK, TDS, ULTRA RAIL END CLAMP 242-02072, 242-02073" in SnapNrack technical data sheet SNR-DC-01338 (rev B), whose SKU/COLOR table lists "242-02073 BLACK", captured on September 25, 2026.
What this shows: what each record says and how far it reaches. It does not mean the product is approved.
StandardEvidenceStatusSource
UL 2703manufacturer claimpresent at observation[3]
Scope
equipment listing
Covered models
242-02073
Limitations
SnapNrack's technical data sheet for part number 242-02073 prints "UL 2703, FILE E359313" in its CERTIFICATION cell. The sheet covers the silver and black versions. Recorded as the manufacturer's claim as printed; the UL directory was not checked.
Printed as "free from defects in materials and workmanship for a period of twenty- five (25) years" in SnapNrack's Manufacturers Limited Product Warranty (rev 11/2020), captured on September 25, 2026. The warranty covers SnapNrack photovoltaic solar mounting products while installed as part of the original system at the original site and starts on completion of installation; a separate five-year finish warranty covers anodized finishes.
SnapNrack's own manual, captured October 15, 2026 with the paced research fetcher (robots.txt read first). Manufacturer instructions, not independent tests.
Archived copies
Archived copy of a document published by SnapNrack. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Original PDF preserved byte for byte, found linked from the Signature Solar listing https://signaturesolar.com/snapnrack-sealing-wood-screw-3/. The revision is whatever was published at this URL on the access date; exact variant coverage inside the document was not separately verified and no later revision was checked.
Archived copy of a document published by res.cloudinary.com. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Captured by scripts/prepare-brand-sweep-sep21.mjs on 2026-09-28.
Location: Product heading and SKU block
Retrieved Sep 27, 2026
SnapNrack product page, captured on September 28, 2026; it prints the product name and the SKU and, where shown, color, weight and dimensions, and links the part's documents. Figures not printed on the page are not recorded from it.
Captured by scripts/prepare-brand-sweep-sep21.mjs on 2026-09-25.
Location: Product tables by system
Retrieved Sep 25, 2026
SnapNrack's own product catalog, hosted on SnapNrack's Cloudinary file host (res.cloudinary.com/summitpoint) and linked as "SnapNrack 2026 Product Catalog" from product pages on snapnrack.com; captured on September 25, 2026. It lists each part by description, SKU and box quantity; it does not print full specifications.
Archived copies
Archived copy of a document published by SnapNrack. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Archived copy of a document published by res.cloudinary.com. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
SnapNrack technical data sheet: Ultra Rail End Clamp (SNR-DC-01338, rev B)
Archived copy of a document published by SnapNrack. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
Archived copy of a document published by SnapNrack. Copyright retained by the publisher; kept for reference and verification only, no endorsement implied. To ask for its removal, email [email protected].
No sourced accessories or replacement parts listed yet.
Model history
Model identity
Model
242-02073
Published model / SKU
242-02073
SnapNrack part number printed for the black version in the SKU/COLOR table of technical data sheet SNR-DC-01338 ("242-02073 BLACK"), captured on September 25, 2026.
