Energy and chemistry
- Nominal voltage
- 12.8 V [2]
- Nominal energy
- 2.56 kWh [2]
- Usable energy
- ?
- Chemistry
- LiFePO4(LFP) [2]
- Cell format
- ?
Charge and discharge
- Continuous charge current
- ?
- Continuous discharge current
- ?
- Maximum charge current
- 100 A [2]
- Maximum discharge current
- 200 A [2]
- Peak charge current
- ?
- Peak discharge current
- ?
- Continuous output power
- ?
- Peak output
- ?
- Maximum charge voltage
- 14.6 V [2]
- Charge cutoff voltage
- ?
- Discharge cutoff voltage
- 10 V [2]
BMS and communication
- BMS continuous current
- 200 A [2]
- Communication protocols
- ?
- Wireless monitoring
- yes [2]
- Inverter compatibility
- ?
Operating temperature
- Charging temperature
- 0 to 45 °C / 32 to 113 °F converted [2]
- Discharging temperature
- -20 to 60 °C / -4 to 140 °F converted [2]
- Storage temperature
- -10 to 45 °C / 14 to 113 °F converted [2]
- Self-heating
- ?
Mechanical and mounting
- Dimensions
- W 190 × H 245 × L 345 mm / W 7.48 × H 9.65 × L 13.6 in converted [2]
- Weight
- 19 kg / 42 lb converted [3]
- Mounting / format
- ?
- Enclosure rating (IP)
- IP65 [2]
Installation (from the manual)
Torque
- Main terminal torque
- 8 ft-lb [2]
- Communication terminal torque
- ?
- Ground terminal torque
- ?
Not in the manual: Conductors, Protection, Clearances and orientation, Grounding, Communication
System limits
- Maximum parallel units
- 4 count [2]
- Series connection
- 4 count [2]
- Maximum system energy
- ?
